# Dovetail column
# Safety shut off switch
# DRO on spindle
# Fine feed head control
# 2 Speed gear box
# Clear guard on spindle
# Rubber chip guards on ways
# Zero setting dials
# Dials read inches
# Tapered gibs throughout
# Forward/Reverse switch
# Stand with chip tray and cabinet
# Motor 1 HP, 110V, 3.2A, single-phase
# Spindle taper R-8
# Spindle travel 2"
# T-slots 3 @ 2-1/2" centers, 3/8" studs
# Head travel 11"
# Head tilt 90°; L/R
# Max. distance spindle to table 13"
# Swing 14-3/4"
# Table travel (longitudinal) 18-7/8"
# Table travel (cross) 6-7/8"
# Table size 7-1/8" x 26-5/8"
# Range of speeds Variable, 50-2250 RPM
# Approximate shipping weight 386 lbs.
# Table Capacity  125-150 lbs.
I got my Grizzly G0704!

These mills are commonly referred to as BF20's with L designating a long table with extra X axis travel. They've been around for years in Europe and Asia along with a few places in North America but with a less desirable MT spindle. R8 spindles are now becoming readily available and with recent editions from Grizzly and others their popularity is booming. I've wanted one for years. Their superior design and quality construction puts the other mills to shame and often for the same or less money. The BF20 is in the same size range as an X3. There are other sizes of BF class mills from 16 to 46. The # is the approximate
drilling capacity in mm's. Use the drop down menus below for much more information. Be sure to check back for new additions as I'll update as new info and projects arise. Scroll down to see pics of my adventure and follow the blog.
01/06/2010
Coming Soon!
I just ordered a G0704 Mill from Grizzly Tools, a CNC conversion and belt drive are first priorities.

Update: Grizzly is expecting a shipment of these mills on Feb. 15th. Time to prepare.
This PDF is for the similar Optimum BF20L Vario.
02/09/2010
Grizzly pushed back the shipment to March 9, good thing with all this snow!
Noticed they posted links to a new pdf manual and parts list. Must still be working on uploading them, I get a server error but they should be available shortly.
02/14/2010
The mill backorder is pushed back till March 25 now it seems. More time time check out some other builds. These BF20's are not new, they've been available in Europe and Asia for years. Folks there have already done conversions and upgrades to them.
These are some links to several I have found, plenty of food for thought for inspiration.

Optimum's BF20 Vario has a CNC conversion kit available. Instructions here.

Syil makes the X5 CNC BF20 Mill. Doesn't seem available in the US though.

Several threads have been made on Cnczone.com by folks sharing their builds.

JBV - Sweden - 2005

Janhenning - Norway - 2008

sgman - Canada - 2008

ellik - Canada - 2010

This german webpage by Zietz shows his servo conversion. Google translated version.
Has plenty of clear pics during the build.

This is an Italian build of a Optimum BF20 Vario in progress. Tero's Project.

This quick video on Youtube shows the guy setting up the BF20's tilting head for use as a lathe.

More youtube videos.

BF20 CNC

Test BF20 with Touchscreen

Optimum BF20 Vario DIY CNC

BF20 cnc

MK2 Drehen Mit der BF20 German Mill as Lathe. More of his BF20 videos.

Cuting with BF 20

BF20 mit Linearführung Teil 2

20.000 RPM check out PEPEFOCO's manymore BF20 videos

BF20 CNC G81 Drilling

BF20 mit automatischem Vorschub Face Milling

BF 20 UREOL (1) quick shot of the Optimum high speed motor adapter.

Huefthalter Deep roughing, more from holgerlauer

BF20 Optimum mit Mach 3 und CNC Tool Controler


02/19/2010
The Mill has been shipped and is currently sitting at the Pitsburgh UPS terminal, looks like I'll have it Monday.

You can keep track of all progress with the mill on my 2 huge threads on Cnczone.
Part 1 -  up to 9/10/10
Part 2 - 9/11/10 to the present.


100_0891_800x600
100_0896_800x600
100_0899_800x600
100_0904_800x600
100_0907_800x600
100_0911_450x600
100_0913_800x600
100_0915_450x600
100_0919_800x600
100_0924_800x600
100_0927_800x600
100_0929_450x600
100_0933_800x600
100_0944_800x600
100_0955_800x600
100_0961_450x600
100_0967_800x600
100_0970_800x600
100_0972_450x600
100_0973_800x600
100_0982_800x600
100_0986_800x600
100_0988_800x600
100_0990_800x600
100_0992_800x600
100_1024_800x600
100_1040_800x600
100_1047crop_800x495
100_1077_800x600
100_1078_800x600
100_1086_800x600
100_1170_450x600
100_1177_800x600
100_1183_800x600
100_1186_800x600
100_1187_800x600
100_1192crop_529x600
100_1197crop_506x600
100_1229_800x600
100_1236_800x600
100_1244_450x600
100_1307_800x600
100_1347_800x600
100_1739_800x600crop
100_2658_800x600
300 IPM test
570 end cover 101_0990_cropped_1000x956
570 stepper end cover lefthand 3
022611 003_cropped_781x600
Chip Tray
031711 051_450x600
032211 033_800x600
032211 036_800x600
ATC 4
TTS Power Drawbar
